5 Linux commands for measuring disk activity

Ever wonder how hard your disks are working? If so, you’re in luck. Linux provides quite a few useful commands for gauging disk activity. This post examines five options that are all very useful and easy to use. This handy suite of commands will help you to see how busy your disks are, not just how full. Two of the commands (iostat and ioping) may have to be added to your system. The iotop command requires that you use sudo privileges.

• dstat
• iostat
• iotop
• ioping
• atop

dstat

All five commands provide useful ways to view disk activity. Probably one of the easiest and most obvious of these commands is dstat. In spite of the fact that the dstat command begins with the letter “d”, it provides stats on a lot more than just disk activity. This includes CPU stats. If you use the command without specifying options, the command displays the data in the format shown below.

$ dstat
You did not select any stats, using -cdngy by default.
----total-usage---- -dsk/total- -net/total- ---paging-- ---system--
usr sys idl wai stl| read  writ| recv  send|  in   out | int   csw
  1   0  99   0   0|   0     0 |  54B  658B|   0     0 | 116   168
  1   0  99   0   0|   0    36k|  54B  338B|   0     0 |  88   138
  0   0  99   0   0|   0     0 |7501B  354B|   0     0 |  62   113
  1   1  97   2   0|   0  1416k|  54B  354B|   0     0 | 159   233
  0   0  99   0   0|   0     0 | 157B  370B|   0     0 |  99   134
  0   0  99   0   0|   0     0 |  54B  354B|   0     0 |  78   113
  1   0  99   0   0|   0     0 |  16k  424B|   0     0 | 107   145
  0   0 100   0   0|   0     0 | 500B  354B|   0     0 |  70   123
  1   0  99   0   0|   0     0 |  54B  354B|   0     0 |  81   127
  0   0  99   0   0|   0     0 |  54B  354B|   0     0 |  84   128
  0   0  99   0   0|   0   272k|  54B  354B|   0     0 |  93   147
  0   1  98   0   0|   0   124k|  54B  354B|   0     0 | 243   387 ^C

Note that the command output displays user, system and idle time along with other stats like disk read and write activity, interrupts and context switches.

The following command displays the top processes related to memory and CPU usage.

$ dstat --top-mem --top-cpu
--most-expensive-- -most-expensive-
  memory process  |  cpu process
gnome-softwa   511|
gnome-softwa   511|btrfs-transa 0.5
gnome-softwa   511|pmdaproc     1.0
gnome-softwa   511|python3      1.5
gnome-softwa   511|kworker/u4:0 1.5

If you want to view just disk activity, you can use the -d option. As shown below, you’ll get a continuous list of disk read/write measurements until you stop the display with a ^c. Note that after the first report, each subsequent row in the display will report disk activity in the following time interval, and the default is only one second.

$ dstat -d
-dsk/total-
 read  writ
 949B   73k
  65k     0

Including a number after the -d option will set the interval to that number of seconds.

$ dstat -d 10
-dsk/total-
 read  writ
 949B   73k
  65k   81M

Notice that the reported data may be shown in a number of different units — e.g., M (megabytes), k (kilobytes), and B (bytes).

The dstat command provides valuable insights into overall Linux system performance, pretty much replacing a collection of older tools, such as vmstat, netstat, iostat, and ifstat, with a flexible and powerful command that combines their features.

iostat

The iostat command helps monitor system input/output device loading by observing the time the devices are active in relation to their average transfer rates. It’s sometimes used to evaluate the balance of activity between disks.

$ iostat
Linux 6.8.9-100.fc38.x86_64 (fedora)    11/05/2024      _x86_64_        (2 CPU)

avg-cpu:  %user   %nice %system %iowait  %steal   %idle
           2.42    0.19    1.44    0.44    0.00   95.52

Device    tps  kB_read/s  kB_wrtn/s  kB_dscd/s  kB_read  kB_wrtn  kB_dscd
loop0    0.11       0.24       0.00       0.00      771        0        0
loop1    0.01       0.02       0.00       0.00       63        0        0
sda     25.13     685.20     175.07     102.58  2194224   560621   328480
zram0    3.98       0.94      15.27       0.00     3000    48900        0

Of course, all the stats provided on Linux loop devices can clutter the display when you want to focus solely on your disks. The command, however, does provide the -p option, which allows you to just look at your disks — as shown in the commands below.

$ iostat -p sda
Linux 6.8.9-100.fc38.x86_64 (fedora)    11/05/2024      _x86_64_        (2 CPU)

avg-cpu:  %user   %nice %system %iowait  %steal   %idle
           2.21    0.17    1.35    0.41    0.00   95.86

Device     tps  kB_read/s  kB_wrtn/s  kB_dscd/s  kB_read  kB_wrtn  kB_dscd
sda      27.40     618.74     162.08    1297.02  2194423   574849  4600040
sda1      0.05       1.70       0.00     167.39     6022        1   593676
sda2      0.05       1.26       0.04     192.96     4469      152   684352
sda3     27.27     615.38     162.04     936.67  2182528   574696  3322012

Note that tps refers to transfers per second.

You can also get iostat to provide repeated reports. In the example below, we’re getting measurements every five seconds by using the -d option.

$ iostat -p sda -d 5
Linux 6.8.9-100.fc38.x86_64   (fedora) 11/05/2024   _x86_64_     (2 CPU)

Device     tps  kB_read/s  kB_wrtn/s  kB_dscd/s  kB_read  kB_wrtn  kB_dscd
sda      25.96     583.46     155.50    1226.91  2194631   584897  4614944
sda1      0.05       1.60       0.00     157.83     6022        1   593676
sda2      0.05       1.19       0.04     181.94     4469      152   684352
sda3     25.84     580.29     155.46     887.14  2182736   584744  3336916

Device     tps  kB_read/s  kB_wrtn/s  kB_dscd/s  kB_read  kB_wrtn  kB_dscd
sda       0.00       0.00       0.00       0.00        0        0        0
sda1      0.00       0.00       0.00       0.00        0        0        0
sda2      0.00       0.00       0.00       0.00        0        0        0
sda3      0.00       0.00       0.00       0.00        0        0        0

If you prefer to omit the first (stats since boot) report, add a -y to your command.

$ iostat -p sda -d 5 -y
Linux 6.8.9-100.fc38.x86_64 (fedora)    11/05/2024      _x86_64_        (2 CPU)

Device     tps  kB_read/s  kB_wrtn/s  kB_dscd/s  kB_read  kB_wrtn  kB_dscd
sda       4.40       0.00      56.00       0.00        0      280        0
sda1      0.00       0.00       0.00       0.00        0        0        0
sda2      0.00       0.00       0.00       0.00        0        0        0
sda3      4.40       0.00      56.00       0.00        0      280        0

Device     tps  kB_read/s  kB_wrtn/s  kB_dscd/s  kB_read  kB_wrtn  kB_dscd
sda       0.00       0.00       0.00       0.00        0        0        0
sda1      0.00       0.00       0.00       0.00        0        0        0
sda2      0.00       0.00       0.00       0.00        0        0        0
sda3      0.00       0.00       0.00       0.00        0        0        0

[ Learn more Linux commands for managing, partitioning, and troubleshooting ]

iotop

The iotop command is a top-like utility for looking at disk I/O. It gathers I/O usage information provided by the Linux kernel so that you can get an idea which processes are most demanding in terms of disk I/O. In the example below, the loop time has been set to 5 seconds. The display will update itself periodically, overwriting the previous output.

$ sudo iotop -d 5
Total DISK READ:       0.00 B/s | Total DISK WRITE:       133.87 K/s
Current DISK READ:     0.00 B/s | Current DISK WRITE:     390.97 K/s
    TID  PRIO  USER   DISK READ DISK WRITE>    COMMAND
    406 be/4 root      0.00 B/s  133.87 K/s [btrfs-transaction]
      1 be/4 root      0.00 B/s    0.00 B/s systemd --switched-root –
system --deserialize=35 rhgb
      2 be/4 root      0.00 B/s    0.00 B/s [kthreadd]
      3 be/4 root      0.00 B/s    0.00 B/s [pool_workqueue_release]
      4 be/0 root      0.00 B/s    0.00 B/s [kworker/R-rcu_g]
      5 be/0 root      0.00 B/s    0.00 B/s [kworker/R-rcu_p]
      6 be/0 root      0.00 B/s    0.00 B/s [kworker/R-slub_]
      7 be/0 root      0.00 B/s    0.00 B/s [kworker/R-netns]
      9 be/0 root      0.00 B/s    0.00 B/s [kworker/0:0H-events_highpri]
     12 be/0 root      0.00 B/s    0.00 B/s [kworker/R-mm_pe]
     14 be/4 root      0.00 B/s    0.00 B/s [rcu_tasks_kthread]
     15 be/4 root      0.00 B/s    0.00 B/s [rcu_tasks_rude_kthread]

[ Related: Learn how to stress test your Linux system ]

ioping

The ioping command is an altogether different type of tool, but it can report disk latency — how long it takes a disk to respond to requests — and can be helpful in diagnosing disk problems.

$ sudo ioping /dev/sda1
4 KiB <<< /dev/sda1 (block device 600 MiB): request=1 time=277.2 us (warmup)
4 KiB <<< /dev/sda1 (block device 600 MiB): request=2 time=477.3 us
4 KiB <<< /dev/sda1 (block device 600 MiB): request=3 time=472.3 us
4 KiB <<< /dev/sda1 (block device 600 MiB): request=4 time=454.8 us

atop

The atop command, like top,  provides a vast assortment of information on system performance, including some stats on disk activity and the amount of load on the system’s resources at the process level.

If you want to look at just the disk stats, you can easily manage that with a command like this:

$ atop | grep DSK
DSK |      sda | busy    1% | read   55761 | write  31218 | avio 0.68 ms |
DSK |      sda | busy    0% | read       0 | write     12 | avio 1.83 ms |
DSK |      sda | busy    0% | read       0 | write     33 | avio 0.73 ms |

To view stats on memory usage, run a command like this one:

$ atop | grep MEM
MEM | tot  3.7G | free  782.1M | cache  1.8G | buff  1.8M | slab  188.7M |
MEM | numnode 1 | shmem 134.5M | shrss  0.0M | tcpsk 0.0M | udpsk   0.0M |
MEM | tot  3.7G | free  780.4M | cache  1.8G | buff  1.8M | slab  188.7M |
MEM | numnode 1 | shmem 134.5M | shrss  0.0M | tcpsk 0.0M | udpsk   0.0M |

Wrap-up

Linux provides enough commands to give you good insights into how hard your disks are working and help you focus on potential problems or slowdowns. Hopefully, one of these commands will tell you just what you need to know when it’s time to question disk performance. Occasional use of these commands will help ensure that especially busy or slow disks will be obvious when you need to check them.
